Global Cynax is offering Thermax make Vapor Absorption Chillers as a cost effective and environment friendly alternative to electricity driven compression chillers. It offers expert solutions in Process Chilling & Air Conditioning for industrial as well as commercial applications. Cooling SBU’s strenght lies in customized solutions as per the requirements of its customers. Cooling capacity range from 100TR – 1000TR (350kW-3500kW).
The operation of Thermax absorption chiller is controlled by stand-alone PLC based control panel. The touch screen HMI provided on the control panel through which the operator can set the necessary set points and can see all the operating parameters, status, alarms, trip logs. The chiller is also equipped with necessary level controls, temperature sensors, flow safety devices etc. to control and safeguard the chiller. For viewing the operating parameters of the chiller from a remote location, MODBUS RTU or Ethernet connectivity is available.
Thermax Vapor Absorption Chillers are powered by:
- Steam (0.1bar-28bar/1.45psig-400psig),
- Hot Water (75DegC-220DegC/170DegF-450DegF)
- Exhaust Gases (From Engine/Turbines)
- Gas/Oil Firing (Natural Gas/Diesel)
Type of Vapor Absorption Chiller
-
Steam Driven Chiller
-
Hot Water Driven Chiller
-
Exhaust Gas Driven Chiller
-
Natural Gas Driven Chiller
-
Hot Water & Exhaust Gas Driven Chiller
